REO A88 Socket FM2/FM2+ mATX Motherboard(Supports all a4, a6, a8, a10 series cpu and all fm2 and fm2+ cpu)
|
Features/Specifications: |
|
|
|
- REO A88 Socket FM2/FM2+ mATX Motherboard(Supports all a4, a6, a8, a10 series cpu and all fm2 and fm2+ cpu)
- General Features:
- mATX form factor
- AMD A88 Express Chipset
- Socket FM2/FM2+ architecture
- Supports up to 16 GB DDR3 1066/1333/1600/1866(OC) /2133(OC) MHz memory
- AMD HD Series high performance DX11 graphics
- Realtek 6 channels
- Realtek 10/100 LAN Controller
- Four (4) Serial ATA 3 GB/s port.
- Expansion Slots:
- One (1) PCI Express x16 slot
- One (1) PCI slots
- Two (2) DDR3 DIMM sockets
- I/O Ports:
- Two (2) PS/2 ports
- One (1) 15-pin VGA port
- One (1) HDMI port
- Two (2) USB 2.0 ports
- Two (2) USB 3.0 ports
- One (1) RJ-45 Ethernet port
- Three (3) 3.5 mm audio jacks
- Internal I/O Ports:
- 24-pin ATX power connector
- 8-pin ATX12V power connector
- Two (2) USB 2.0 headers
- Front panel audio header
- 4-pin Processor fan header
- 4-pin chassis fan header
- Front panel header
- Speaker header
- Front USB 3.0 header
- Serial Port Header
- Supported Processors:
- Support FM2/FM2+ interface processor
- Box Dimensions : 10.45 W x 2.75 H x 10.20 D (inch)
- Box Weight : 690 grams
- Product Dimensions : 8.6 W x 1.6 H x 6.5 D (inch)
- Product Weight : 430 Grams
|
|
Package Includes: |
|
|
|
- REO A88 Socket FM2/FM2+ mATX Motherboard(Supports all a4, a6, a8, a10 series cpu and all fm2 and fm2+ cpu)
- Driver Disc
- SATA cable
- I/O shield
|
|
Additional Information: |
|
|
|
- Notes:
- Model: AMD FM2+ D3
- Product Requirements:
- ATX/mATX case
- Power supply
- Supported processor
- Supported RAM
- Rest of system
|
|
